2024 JAC Refine RefineRF8 PHEV 1.5T 163HP L4 3DHT PHEV 27.6KWH

Brand

JAC Refine

Series

RefineRF8 PHEV

Manufacturer

JAC Refine

Model

2024 JAC Refine RefineRF8 PHEV 1.5T 163HP L4 3DHT PHEV 27.6KWH

MSRP

239900.00

Launch Time

2024.01

Class

Full-size MPV

Fuel Type

PHEV

Frame Structure

Unibody

Body Structure

MPV

Doors

5

Seats

●7
○6

Body Type

5doors 7seats MPV

Top Speed(km/h)

180

Manufacturer 0-60km/h Acceleration Time(s)

7.3

Emission Standard

CHN VI

Maximum Power(kW)

310

Maximum Torque(N·m)

745

Battery Type

Lithium Iron Phosphate Battery（LFP）

Battery Capacity (kWh)

27.6

Electricity Consumption (kWh/100Km)

15.1

Fast Charge Percentage (%)

30-80

Battery Cell Brand

Calb

Fast Charging Function

Supported

CLTC Range (km)

150

Battery Cooling Method

Liquid cooling

Fast Charge Percentage(%)

30-80

Equivalent Fuel Consumption Of Electricity(L/100km)

2.21

CLTC Range(km)

150

Fast Charging Power

42

WLTC Range (km)

116

WLTC Range(km)

116

Front Brake Type

Ventilated Disc

Rear Brake Type

Ventilated Disc

Parking Brake Type

Electric Parking Brake

Aircondition Control

Automatic

Interior Rearview Mirror Function

●Manual Dim
○Auto Dim

Multimedia/Charging Interface

USB
Type-C

Usb/Type-C Interface Quantity

Front2/Rear4

Ambient Light

64 Colors

Mobile Wireless Charging

Front

Mobile Wireless Charging Power

50W

Key Type

Remote key
UWB digital key

Keyless Entry

All Positions

Voice Wake-Up Recognition In Specific Areas

Two areas

Length(mm)

5215

Width(mm)

1895

Height(mm)

1830

Body Wheelbase(mm)

3100

Front Track(mm)

1611

Rear Track(mm)

1623

Dimension

5215*1895*1830

Fully Loaded Ground Clearance(mm)

130

Approach Angle(°)

15

Departure Angle(°)

15

Unladen Minimum Ground Clearance(mm)

180

Minimum Turning Radius(m)

6.2

Front/Rear Power Windows

Front / Rear

Exterior Rearview Mirror Function

●Electric Adjustment
●Electric Folding
○Memory
●Heating
○Auto Tilt
●Auto Folding

One Touch Window Control

All Positions

Multilayer Soundproof Glass

Front Seats

Sliding Door Form

Dual electric

Vanity Mirrors

Driver Seat
Passenger Seat+Light

Rain-Sensing Wipers

Rain Sensing

Sunroof Type

Segmented Electric Sunroof

Door Opening Style

Front hinged doors+Side sliding doors

Drive Mode

Front-Engine
Front-Wheel Drive

Driving Mode Switch

Sport
Eco
Standard/Comfort
Snow

Front/Rear Parking Radar

Front / Rear

Number of in-car cameras

1

Drive Assistance Image

360° surround view

Number Of Cameras

5

Number Of Ultrasonic Radars

8

Number Of Millimeter-Wave Radars

2

Cruise Control System

Full Speed Range Adaptive Cruise Control

Map Brand

Amap

Advanced Driving Assistance Level

L2

Vehicle Intelligent Chip

Qualcomm Snapdragon6125

Motor Type

Permanent-magnet Synchronous Motor

Total Motor Power (kW)

160

Total Motor Torque (N·m)

350

Front Motor Maximum Power (kW)

160

Electric Motor(Ps)

218

Front Motor Maximum Torque (N·m)

350

Total System Power (kW)

310

Total System Torque (N·m)

745

Number Of Motors

1

Motor Layout

Front

Total Motor Power (Ps)

218

Total System Power (Ps)

422

Emission Standard

CHN VI

Maximum Power(kW)

120

Maximum Torque(N·m)

255

Engine Model

BHE15-BFZ

Displacement (mL)

1499

Displacement (L)

1.5

Engine

1.5T 163HP L4

Intake Form

Turbo Charge

Cylinder Arrangement Form

L

Number Of Cylinders

4

Number Of Valves Per Cylinder

4

Valve Mechanism

DOHC

Maximum Horsepower (Ps)

163

Maximum Power Speed(rmp)

5500

Maximum Torque Speed(rmp)

2500-4000

Engine Exclusive Technology

Miller cycle

Fuel Type

PHEV

Fuel Label

92#

Fuel Supply Mode

Direct injection

Cylinder Head Material

Aluminum Alloy

Cylinder Block Material

Aluminum Alloy

Engine Layout

Transverse

Maximum Net Power(Kw)

115

WLTC Fuel Consumption(L/100km)

1.27

Minimum State Of Charge Fuel Consumption(L/100Km)

5.4

Number Of Speakers

12Speakers

Low Beam

LED

High Beam

LED

Driver/Passenger Airbags

Driver Seat / Passenger Seat

Front/Rear Side Airbags

Front / Rear-

Front/Rear Head Airbags (Curtain)

Front / Rear

Seatbelt Reminder

Front Seats
Rear Seats

Lcd Console Screen

LCD Touch Screen

Console Screen Size(inch)

12.3inches

Speech Recognition Control System

Multimedia System
Navigation
Phone
Air Conditioner
Sunroof
Window

Driving Computer Display Screen

Color

Lcd Dashboard Size

12.3inches

In-Car Intelligent System

Zhi Ling

Seat Material

Artificial leather

Driver Seat Adjustment

●Forward/Backward Adjustment
●Backrest Adjustment
●Up/Down Adjustment(2-Way)
○Lumbar Support(4-Way)

Passenger Seat Adjustment

Forward/Backward Adjustment
Backrest Adjustment

Front Power Seats

Driver Seat● / Passenger Seat○

Front Seat Function

○Heating
○Ventilation
●Heating(Driver Seat Only)
●Ventilation(Driver Seat Only)

Seats Memory

○Driver Seat

Rear Seat Adjustment

Forward/Backward Adjustment
Backrest Adjustment
Lumbar Support
Thigh Extension

Rear Seat Function

Heating
Ventilation
Massage

Rear Seats Tray Table

○

Seat Layout

○2-2-2
●2-2-3

Rear Seats Folding Form

Split-folding

Center Armrest

Front / Rear

Third Row Seat Adjustment

Forward/Backward Adjustment
Backrest Adjustment

Steering Wheel Material

Genuine leather

Steering Wheel Adjustment

Manual

Power Steering Type

Electric Power Steering

Shifting Form

Electronic gear lever shift

Front Suspension Type

McPherson independent suspension

Rear Suspension Type

Multi-link independent suspension

4G/5G Network

4G

Mobile Connect

Original Mobile Connect

Mobile App Remote Control

Door
Window
Engine
Charging
Air condition
Seat heating
Seat Ventilation
Vehicle diagnosis
positioning/searching

Rim Material

Alloy

Front Tire Specs

225/55 R18

Rear Tire Specs

225/55 R18

Number Of Gears

3

Transmission Type

DHT

Transmission Abbreviation

3DHT

Transmission

3-Speed Dedicated Hybrid Transmission

Warranty

5yr. / 100000km.

Fuel Tank Capacity(L)

54

Rear Trunk Volume(L)

700-2500

Curb Weight(kg)

2330

Maximum Laden Mass(Kg)

2895
